Shims are elements that mechanically correct the Z offset when printing in Mirror or Duplication mode. These printing modes are available for all Sigmax versions, for the Sigma R19 and for the BCN3D Epsilon. Those Sigma users who have previous versions must update their firmware to 2.0.0 or higher to have them available. Visit our Support page to learn how to do it.
In these modes both toolheads work simultaneously, so it is key important to make sure both nozzle tips are exactly at the same height. Due to manufacturing and assembly tolerances the Z offset between tips can be up to 0.5mm. BCN3D printers automatically correct the offsets when printing in Mirror/Duplication Modes. However, this correction distorts the first layer of the model by repeating it as many time as needed. To avoid such distortion there are different options:
1. Enable raft in BCN3D Cura.
The offset will be corrected in the first layers of the raft, so the model won’t be affected by any Z offset.
2. Install shims to mechanically correct the Z offset.
Printing a raft takes time and spends material. For those users planning to use frequently the Mirror or Duplication modes, it is highly recommended to install the shims when it is suggested during the Printer Calibration process.
How to install it?
The installation process is step-guided by the printers. See how to install them in the Support website.
