BCN3D EPSILON W50
Their trust is our best argument
Industrial power
on your workbench.
Create big functional parts with solid mechanical properties.
Unlock a wide range of technical applications with the industrial-grade BCN3D Filaments, developed by the renowned chemical companies: BASF and Mitsubishi Chemical, or work confidently with any third-party material of your choice thanks to our Open Filament System.
In Development:
Standard: rPET / TPU 85A
Technical: ASA / HIPS
Developed by BCN3D, the disruptive Independent Dual Extrusion System technology makes the difference in 3D printing.
-
Duplication mode
Duplication Mode
A setting that prints identical models simultaneously, doubling the production capacity.
-
Mirror Mode
Mirror Mode
A mode that enables printing mirrored designs symmetrically and speeds up iteration.
-
Soluble Supports Mode
Soluble Supports Mode
A process that prints soluble parts to create intricate structures and avoid geometric limitations.
-
Multimaterial Mode
Multimaterial Mode
A technique that makes it possible to print two different materials and combine their properties.
Massive print volume
Epsilon W50
Volume: 50 Liters
Epsilon W27
Volume: 27 Liters
Epsilon W50
Volume: 50 Liters
Epsilon W27
Volume: 27 Liters
SMART CABINET
Interested in adding a Smart Cabinet to your current Epsilon? Get in touch with your supplier now to save 495€ (offer available till July 18 2021)
Key Features
Key Features
Print while in storage
The dehumidifier can fit up to 10 small spools (weight between 750 g - 1 kg and width up to 55mm) or 4 big spools (weight up to 2,5kg). These can be loaded to your 3D printer directly from this humidity-controlled environment, therefore allowing it to print while keeping the materials in perfect condition.
Humidity-controlled environment
Designed to extend the service life of your materials, the alumina absorbs the moisture from the air in the chamber. Once it becomes saturated, this material is isolated from the filaments and gets heated up until it releases the moisture, purging it out of the system. This process effectively keeps the filament dry and in optimal condition for its use.
Complete working station
The tool drawer provides you with every utensil you might need, and thanks to the extra space for your laptop or tablet you count on a full working station right by your 3D printer.
Uninterruptible Power Supply (UPS)
The UPS electric signal filtering protects your print from any possible outages and micro-cuts on the electric current. In the event of a blackout of up to 10 minutes, this technology will enable the 3D printer to automatically resume the printing process once the power is back. In case of a longer outage, the UPS will save the printer’s last position, so that you can manually resume the printing process at any time and without consequences for your print.
Storage and transportation
Maintain your workspace organized and clean at all times thanks to the ample storage space, designed to keep extra building plates and unopened filament spools - and thanks to the Smart Cabinet’s transportable structure, your printer can be easily moved across your facilities.
Designed to perform.
Full enclosure &
passively heated chamber.
The Epsilon W50 and the Epsilon W27 count on a fully enclosed chamber keeping internal temperature controlled, where it can reach up to 60°C, and a heated bed reaching up to 120°C.
Safety first
-
HEPA filter
The BCN3D Epsilon printers are equipped with a HEPA filter, which protects your working environment from potentially harmful particles when printing with industrial materials.
-
Safety pause
The Safety Pause feature will stop the printing process every time the enclosure door is opened, so that your experience will be fully safe through and through.
-
CARBON filter
The carbon filter on the BCN3D Epsilon printers shields your environment from any potentially harmful fumes produced by the materials used.
-
HEPA filter
The BCN3D Epsilon printers are equipped with a HEPA filter, which protects your working environment from potentially harmful particles when printing with industrial materials.
-
Safety pause
The Safety Pause feature will stop the printing process every time the enclosure door is opened, so that your experience will be fully safe through and through.
-
CARBON filter
The carbon filter on the BCN3D Epsilon printers shields your environment from any potentially harmful fumes produced by the materials used.
Key Features
Key Features
Bondtech™ Extruders
This extruder features high-tech dual drive gears by Bondtech™, offering more control, sharper details, and superior performance for any type of filament.
Filament Runout Sensor
A job-saving sensor that detects when the filament is finished and pauses the printing process until it is reloaded again.
e3D™Hotends
The hotends have been carefully designed by e3D™ to deliver the smoothest and most reliable extrusion.
Heated bed up to 120ºC
The BCN3D Epsilon Series is equipped with a heated bed that can reach up to 120ºC, ideal to print with engineering-grade materials and avoid warping issues.
Multilingual 5’’ touchscreen
The BCN3D Epsilon Series is equipped with a multilingual intuitive interface that guides you through its advanced features. Supported languages: German, English, Spanish, French, Italian, Japanese, Portuguese, Chinese.
Aluminium frame
Sturdy aluminum frame for guaranteed strength and durability on your workfloor.
Move to fiber.
Move to Hotend X.
The Epsilon W50 and Epsilon W27 can be paired with the new Hotend X, designed to print seamlessly with fiber-filled materials. This enables printing sturdier parts for the most demanding applications.
Sold separately
In Depelopment: PET CF15 / 316L
A Unique Ecosystem
-
BCN3D Cloud
The BCN3D Epsilon 3D printers are equipped with the latest connectivity features. Easily send your print files when connected to the network for a hassle-free workflow with our BCN3D Cloud platform. And forget about manual firmware upgrades thanks to Over The Air (OTA) updates, who will ensure that your printer is always up to date (activated on demand).
-
BCN3D Cura
“}” data-sheets-userformat=”{“2″:23361,”3”:{“1″:0},”9″:1,”11″:4,”12″:0,”14”:{“1″:2,”2″:0},”15″:”Arial”,”17″:1}” data-sheets-textstyleruns=”{“1”:0}{“1″:11,”2”:{“5″:0}}”>Our intuitive, versatile, and detailed software prepares all types of industry-level models for 3D printing.
-
BCN3D Filaments
Industrial-grade materials manufactured by BASF and Mitsubishi Chemical and designed to deliver outstanding results for BCN3D printers.
-
BCN3D Hotend family
A wide range of nozzle sizes which enables printing anything from small, very precise details to massive, solid parts in less time.
-
BCN3D Cloud
The BCN3D Epsilon 3D printers are equipped with the latest connectivity features. Easily send your print files when connected to the network for a hassle-free workflow with our BCN3D Cloud platform. And forget about manual firmware upgrades thanks to Over The Air (OTA) updates, who will ensure that your printer is always up to date (activated on demand).
-
BCN3D Cura
“}” data-sheets-userformat=”{“2″:23361,”3”:{“1″:0},”9″:1,”11″:4,”12″:0,”14”:{“1″:2,”2″:0},”15″:”Arial”,”17″:1}” data-sheets-textstyleruns=”{“1”:0}{“1″:11,”2”:{“5″:0}}”>Our intuitive, versatile, and detailed software prepares all types of industry-level models for 3D printing.
-
BCN3D Filaments
Industrial-grade materials manufactured by BASF and Mitsubishi Chemical and designed to deliver outstanding results for BCN3D printers.
-
BCN3D Hotend family
A wide range of nozzle sizes which enables printing anything from small, very precise details to massive, solid parts in less time.
